RC-17 Temperature Data Logger Single Use

The RC-17 temperature data logger is a single use low-cost recorder that alerts you if your shipment has fallen out of the refrigeration zone (2°C – 8°C).
Requiring no software and with preset temperature alarm limits, the RC-17 is a simple solution for monitoring your refrigerated shipments.

The RC-17 temperature data logger is a low-cost recorder that alerts you if your shipment has fallen out of the refrigeration zone (2°C – 8°C).
Requiring no software and with preset temperature alarm limits, the RC-17 is a simple solution for monitoring your refrigerated shipments.
RC-17 is waterproof to IP67 and meets HACCP requirements for food safety.
The RC-17 is powered by a CR2450 button battery and has compliance for aviation safety certification.
This disposable temperature recorder is packed in a waterproof bag, monitoring data without taking it out of the bag.

Features

check box

Track the entire cold chain in real-time and generate PDF data report automatically

check box

Auto encrypted data report generated upon direct USB insertion into a PC or Mac

check box

Powered by button battery CR2450, compliance to aviation safety certification

check box

Thin 8mm housing—easily slips into standard packaging

check box

Waterproof IP67 meets HACCP requirements for food safety

check box

1-year warranty

How to Use

RELATED PRODUCTS

RC-17N Temperature Recorder

COVID-19 Vaccine Monitor

timestrip time indicator 12 hours

Timestrip Time Indicator

TempU04 Temperature Recorder

Specifications

Temperature measuring range
-30℃~70℃/-22℉~158℉
Resolution
0.1℃/℉
Accuracy
±0.5℃/±0.9℉(@-20℃~40℃/-4℉~104℉); 1℃/1.8℉(@others)
Memory capacity
16000 readings
Recording period
6, 15, 30, 60, 90, 120, 180 days (customizable)
Alarm type
single or cumulative
Report type
PDF format
Data interface
USB2.0
Sensor type
Internal NTC
Power supply
Built-in CR2450 wide temperature lithium battery
Battery life
2 years (stored and used under normal temperature environment)
Protection grade
IP67
Dimension
93mm (L) x 58mm (W) x 8mm (H)
Weight
20g

Documents

Adobe_PDF_file_icon_32x32

RC-17 Temperature Data Logger Sales Sheet

Adobe_PDF_file_icon_32x32

RC-17 Temperature Data Logger User Manual
