Impact and Environmental Recorders Product Specifications

ShockLog 298

Operating Temperature Range

-40°F / -40°C to 185°F / 85°C

Size

4.8" / 123mm x 3.1" / 78mm x 2.2" / 55mm

Weight

1.1lbs / 515g (without battery)

Battery

2 x 3.6V Lithium Thiorxyl Chloride
2 x 1.5V Alkaline Size AA

Case Material

Aluminum

Scale Factor Accuracy at 5G

+/- 2%

Additional Error Other Ranges

+/- 2%

Acceleration Range

+/- 1 to +/- 200G

Cut-off Frequency Options (Programmable)

10Hz, 40Hz, 90Hz, 120Hz, and 250Hz

Wake-Up Threshold (% of Range)

5–95%

Warning and Alarm Threshold (% of Range)

5–95%

Wake-Up Time

0.25mS

External Power Source Option

4.5V min / 30V max

ShockLog 248

Operating Temperature Range

-40°F / -40°C to 185°F / 85°C

Size

3.3" / 84mm x 3.3" / 84mm x 2.2" / 55mm

Weight

1.1lbs / 445g (without battery)

Battery

1 x 3.6V Lithium Thiorxyl Chloride
1 x 1.5V Alkaline Size AA

Case Material

Aluminum

Scale Factor Accuracy at 5G

+/- 5%

Acceleration Range

+/- 10G, +/- 30G, +/- 100G

Cut-off Frequency Options (Factory Set)

40Hz, 90Hz, and 250Hz

Wake-Up Threshold (% of Range)

5–95%

Warning and Alarm Threshold (% of Range)

5–95%

Wake-Up Time

0.25mS

ShockLog 208

Operating Temperature Range

-40°F / -40°C to 185°F / 85°C

Size

3.3" / 84mm x 3.3" / 84mm x 2.2" / 55mm

Weight

1.1lbs / 445g (without battery)

Battery

1 x 3.6V Lithium Thiorxyl Chloride
1 x 1.5V Alkaline Size AA

Case Material

Aluminum

Acceleration Range

+/- 10G, +/- 30G, +/- 100G

Cut-off Frequency Options (Factory Set)

40Hz, 90Hz, and 250Hz


Accessories
Tilt & Roll Accelerometer Specifications

Operating Temperature Range

Standard -40 to 85°C

Size

3.3" / 84mm x 3.3" / 84mm x 1.9" / 47mm

Weight

317.51g (without battery)

Battery

2 x 3.6V Lithium Thionyl Chloride

Case Material

Aluminium, IP67 Rating

Tilt Range Monitored

+/-90°

Resolution

0.3°

Transverse Sensitivity

5%

Noise (rms)

DC-30

eTrak Specifications

Operating Temperature Range

-40°C to 85°C

Size

6.3" / 160mm x 9.8" / 250mm x 1.6" / 40mm

Weight

1.53lbs / 696g

Power Supply

Solar panel, trickle charge to 680mA hour LiOn battery

Case Material

ABS

Regions

Global provided GSM network coverage available



External Temperature, Humidity, and Pressure Sensor Specifications

Temperature Measuring Range

-40°F/-40°C to +185°F/+85°C

Humidity Measuring Range

0 — 100% RH

Pressure Measuring Range

0 — 1.1 bar (standard)
